Load Cell Array Measurement System

The load cell array measurement system consists of Inputs to 4 load cells. The load cell output is passed through a zero-drift Instrumentation amplifier and sampled by a 12 bit ADC inside the ESP32 WROVER module which is multiplex and sample the systems.

Category:
Description

Where to use?

    1. Weight Distribution Measurement

Modules used are

          1. Power supply board
          2. 2 nos of Analog Input Board
          3. 2 Variable gain Instrumentation Amplifier
          4. 24 bit 16 channel ADC
          5. Processor Module
